Modular Parallel LiFePO4 Battery Pack 72V 52Ah to 520Ah for Electric Power Systems Best Li-ion Battery Pack

  • Modular Parallel LiFePO4 Battery Pack 72V 52Ah to 520Ah for Electric Power Systems Best Li-ion Battery Pack
  • Modular Parallel LiFePO4 Battery Pack 72V 52Ah to 520Ah for Electric Power Systems Best Li-ion Battery Pack
  • Modular Parallel LiFePO4 Battery Pack 72V 52Ah to 520Ah for Electric Power Systems Best Li-ion Battery Pack
  • Modular Parallel LiFePO4 Battery Pack 72V 52Ah to 520Ah for Electric Power Systems Best Li-ion Battery Pack

Modular Parallel LiFePO4 Battery Pack 72V 52Ah to 520Ah for Electric Power Systems Best Li-ion Battery Pack

    Min. Order: 20 Pack/Packs

Basic Info

Model No.: 72V 52Ah 104Ah 208Ah 416Ah

Product Description

Modular Parallel LiFePO4 Battery Pack 72V 52Ah to 520Ah

for Electric Power Systems Best Li-ion Battery Pack

Product Introduction

Compared with conventional Lithium Battery packs, DADNCELL has obvious advantages:

1. Unique battery module parallel technology, so that after the battery modules are connected in parallel, any group of them will not affect the operation of Other modules;

2. Support multiple battery packs to be used in parallel to increase battery capacity.

DADNCELL’s main 12/24/48/60/72V 52/104/208Ah series Battery Pack products use lithium iron phosphate battery cells (60mm direct large cylinder), equipped with a BMS centralized monitoring module, and support 10 battery modules in parallel It can be used interchangeably with lead-acid battery packs of the same voltage when the number of charging cycles is more than 3000 times. It has multiple communication modes to realize remote management. At present, it is widely used in electric four-wheeled vehicles, tricycles, sightseeing vehicles, storage vehicles, ships, energy storage power supplies, emergency power supplies and other fields.

Product parameter

Project 12V Series 24V Series 48V Series 60V Series 72V Series
12.8V208Ah 25.6V104Ah 51.2V52Ah 64V52Ah 76.8V52Ah
Nominal voltage (V) 12.8V 25.6V 51.2V 64V 76.8V
Nominal capacity (Ah) 204Ah 102Ah 52Ah 52Ah 52Ah
Charging voltage (V) 14.6V 29.2V 58.4V 73V 87.6V
Charging current (A) 30A 30A 30A 30A 30A
Discharge cut-off voltage 10V 20V 40V 50V 60V
Discharge current 100A 80A 60A 60A 60A
Short circuit protection Short circuit protection
Automatic recovery after disconnecting the load
Charging temperature 0℃~55
The discharge temperature -10℃~65
Storage temperature -20℃~+60
Working relative humidity ≤95%45±2℃)
Relative humidity of storage and transportation ≤95%45±2℃)
Cycle life ≥3000
Size mm 390×143×270±2 390×143×270±2 300×227×270±2 365×227×270±2 430×227×270±2
Weight KG 20±0.2 20±0.2 22±0.2 27±0.2 31±0.2
Communication methods UART UART UART UART UART

Ev Car Battery


2222333444

555555

6666777


4

About us

Huachuang Times is an advanced battery technology company in China, focusing on R&D and production in the field of batteries, insisting on taking science and technology as the forerunner, focusing on products and focusing on customers.
The company has established a technology center and a post-doctoral scientific research station, and has established a number of new energy research centers in cooperation with national key universities and the Institute of Chinese Academy of Sciences. The scientific research and innovation mechanism is mature and complete. As a company with strong scientific and technological strength in the battery field in China, it will be committed to Users provide power products and services with brand-new technology and experience.

88899910000111122


Shandong Huachuang Times Optoelectronics Technology Co., Ltd.

 Huachuang Times is an advanced battery technology company in China, focusing on R&D and production in the field of small batteries, insisting on taking science and technology as the forerunner, focusing on products and focusing on customers.

The company has established a technology center and a post-doctoral scientific research station, and has established a number of new energy research centers in cooperation with national key universities and the Institute of Chinese Academy of Sciences. The scientific research and innovation mechanism is mature and complete. As a company with strong scientific and technological strength in the battery field in China, it will be committed to Users provide power products and services with brand-new technology and experience.

Today, the company's products have been sold to more than 60 countries and regions on five continents in the world, fully demonstrating the excellent quality of Chinese products and the strong charm of national enterprises to consumers.
